10.3 inch 1920*720 IPS Screen 1000nits LVDS Interface TFT LCD Display Modules
| Inch | 10.3 |
| Part number | TST103HDKK-02 |
| Res. | 1920xRGBx720 |
| Outline mm | 253.15x106.01x6.81 |
| AA mm | 243.65x91.37 |
| Viewing | ALL |
| Contr. | |
| interface | LVDS |
| lumin. | 1000 |
| Driver IC |
Brand:
TSD
Spu:
TST103HDKK-02
Appurtenance:
- Overview
- Related Products
10.3 inch 1920*720 IPS Screen 1000nits LVDS Interface TFT LCD Display Modules
1.1 Introduction
This is a color active matrix thin film transistor (TFT) liquid crystal display (LCD) that uses a-Si and transmissive TFT as a switching device with normal-blacktechnology. It is composed of a TFT LCD panel, driver IC and back-light. The TFT LCD has 10.3 inch with 1920 x 720 resolution and RoHS directive.
1.2 Features
10.3 (8:3 diagonal) inch configuration
Landscape type
Fail detect finction
Parallel RGB 8 bits (16.7M)
1.3 Applications
TFT LCD MonitorIndustrial Application
Amusement
Vehicle
| Inch | 10.3 |
| Part number | TST103HDKK-02 |
| Res. | 1920xRGBx720 |
| Outline mm | 253.15x106.01x6.81 |
| AA mm | 243.65x91.37 |
| Viewing | ALL |
| Contr. | |
| interface | LVDS |
| lumin. | 1000 |
| Driver IC |
Have any customize requirements, please feel free to contact us.
