Customized yellow green blue 16x2 monochrome stn mono 3.3v 5v 1602 2*16 character lcd display
| Part number | TSM1602-20B | TSM1602B-L |
| Dots Resolution | 16x2 | 16x2 |
| Outline (mm) | 80x36x13 | 122x44x12.8 |
| View area (mm) | 64.37x14.8 | 99x24 |
| Active area (mm) | 55.7x11 | 94.8x19.9 |
| Voltage | 5V | 5V |
| View Direction | 6:00 | 6:00 |
| IC | ST7066-0B | AIP31066 |
| Display Mode | STN-YG, transflective | STN-YG, transflective |
Brand:
TSD
Spu:
TSM1602
- Overview
- Related Products
Customized yellow green blue 16x2 monochrome stn mono 3.3v 5v 1602 2*16 character lcd display
Products Description
Type |
STN/FSTN/transflective |
Display Size |
16x2 display |
Supplier Type |
manufacturer |
LCD Type |
custom mono stn lcd module |
Display type |
STN/FSTN/Transflective |
Numbers of Characters |
8*1/16*2/16*1/20*2/20*4 |
Polarizer mode |
Positive, transflective |
Operating Temperature |
5V/3.3V |
Backlight |
yellow green blue |
| Part number | Dots Resolution | Outline (mm) | View area (mm) | Active area (mm) | Voltage | View Direction | IC | Display Mode |
| TSM1602-20B | 16x2 | 80x36x13 | 64.37x14.8 | 55.7x11 | 5V | 6:00 | ST7066-0B | STN-YG, transflective |
| TSM1602B-L | 16x2 | 122x44x12.8 | 99x24 | 94.8x19.9 | 5V | 6:00 | AIP31066 | STN-YG, transflective |
Have any customize requirements, please feel free to contact us.
