5.7 Inch 640x480 Sunlight Readable 1000nits High Brightness SPI+RGB24-bit/ MIPI Interface IPS TFT LCD Module
Excellent 5.7-Inch IPS TFT LCD Module Performance. And with a maximum brightness of 1000 nits it is readable in sunlight, and is unafraid of bright light environments. 640x480 resolution and RGB color mode ensure full rich colors and crisp images. MIPI DSI interface also provide stable, high-speed data transmission and low power consumption. Providing products with reliable and excellent display experience for outdoor equipment, industrial terminals, etc.
|
Model Number
|
TST057VGBE-04B
|
|
Display Type
|
5.7 Inch TFT LCD Display Module
|
|
Resolution
|
640xRGBx480
|
|
Outline Size
|
127x98.43x5.8mm
|
|
Active Size
|
115.2x86.4mm
|
|
View Direction
|
All
|
|
Interface
|
SPI+RGB24-bit/ mipi DSI
|
|
Surface Lumiannce
|
1000(nits)
|
|
Driver IC
|
JD9168S
|
Brand:
TSD
Spu:
TST057VGBE-04B
Appurtenance:
- Overview
- Related Products
5.7'' 5.7 Inch 640x480 Resolution RGB MIPI DSI Interface IPS TFT LCD Display Module With JD9168S Driver IC |
||
Model Number |
TST057VGBE-04B |
|
Display Type |
5.7 Inch TFT LCD Display Module |
|
Resolution |
640xRGBx480 |
|
Outline Size |
127x98.43x5.8mm |
|
Active Size |
115.2x86.4mm |
|
View Direction |
All |
|
Interface |
SPI+RGB24-bit/ mipi DSI |
|
Surface Lumiannce |
1000(nits) |
|
Driver IC |
JD9168S |
|
Operating Temperature |
-20--+70/-30--+85(℃) |
|
Storage Temperature |
-30--+80/-40--+90(℃) |
|
Brand |
TSD |
|
Custom Service |
FPC, CTP (capacitive touch panel), RTP (resistive touch panel), pin definition, packing, HD-MI board |
|
Have any customize requirements, please feel free to contact us.
