7 inch 800*480 HDMI interface Touch Screen TFT LCD Display Modules
| Item |
7 inch HDMI TFT LCD display |
| Model name | TSM070WVBE-101C |
| Display Mode | Normally White,Transmissive |
| Resolution | 800*480 |
| Technology Type | a-Si TFT active matrix |
| Driver IC | EK9716+EK73002 |
| Pixel Configuration | R.G.B. Vertical Stripe |
| Outline Dimension | 164.90x100.00x3.25 |
| Active Area(mm) | 154.08x85.92 |
| Interface | HDMI |
| Viewing Direction | 12H |
| Surface treatment: | Anti-Glare |
| Backlight Type | 1-LED white color |
| Operating Temperature | -20~70°C |
| Storage Temperature | -30~+80°C |
Brand:
TSD
Spu:
TSM070WVBE-101C
Appurtenance:
- Overview
- Related Products
7 inch 800*480 HDMI interface Touch Screen TFT LCD Display Modules
| Main parameters: | |
| Item | 7 inch TFT LCD display |
| Model name | TSM070WVBE-101C |
| Display Mode | Normally White,Transmissive |
| Resolution | 800*480 |
| Technology Type | a-Si TFT active matrix |
| Driver IC | EK9716+EK73002 |
| Pixel Configuration | R.G.B. Vertical Stripe |
| Outline Dimension | 164.90x100.00x3.25 |
| Active Area(mm) | 154.08x85.92 |
| Interface | HD-MI |
| Viewing Direction | 12H |
| Surface treatment: | Anti-Glare |
| Backlight Type | 1-LED white color |
| Operating Temperature | -20~70°C |
| Storage Temperature |
-30~+80°C |
Have any customize requirements, please feel free to contact us.
