TSD 2.1 inch 480x480 Round Screen SPI RGB Interface Round IPS TFT LCD Display Modules
Compact 2.1-inch round IPS TFT LCD with 480×480 resolution, delivering vivid full-color visuals and wide viewing angles. 350 cd/m² brightness ensures clear readability, while the ST7701S driver and MCU interface enable easy integration. Operating from -20°C to +70°C, it suits wearables, smart home controls, and industrial devices. Custom options include FPC, CTP/RTP touch, and higher-brightness versions.
- Overview
- Related Products
1. More than 20 years experience, strong background in TFT and P-cap design.
2. Faster Support in Front and After-sales service. Support customer from the products' design to the final products.
3. Local sales and engineer team support in European for good communication.
4. Follow a people-oriented, quality and customer-first approach in all of our dealings, fast developing together with customers.Follow a people- oriented, quality and customer-first approach in all of our dealings, fast developing together with customers.
| About this product |
TST020WVBS-08 is a 2.1 inch round TFT LCD. The 2.1'' round color display is 480x480 resolution. The 2.1 inch round LCD module is IPS wide viewing angle, and it supports MCU interface. The 2.1 inch LCD screen is 350nits brightness now, but we can customize a high brightness round screen for you. We can use higher brightness backlight lamps or make some other adjustments to the current backlight.
In addition, we can produce 2.1 inch round touch screen also. Both capacitive touch panel and resistive touch panel are supported, and we can make different color, size, and shape of the 2.1'' touch panel.
The 2.1 inch round display is very suitable for smart wearable devices like smart watch and medical watch.
LCD type |
2.1 inch round IPS TFT LCD display |
Part No. |
TST020WVBS-08 |
Resolution |
480xRGBx480 |
Viewing angle |
IPS |
Drive IC |
ST7701S |
Interface |
MCU |
Brightness |
350 cd/m2 |
Operation temperature |
-20℃ to +70℃ |
Storage temperature |
-30℃ to +80℃ |
Brand |
TSD |
Custom Service |
FPC, CTP (capacitive touch panel), RTP (resistive touch panel), pin definition, packing, HD-MI board |
| About US |
 |
Who is TSD? TEAM SOURCE DISPLAY (TSD) was established in 2004.
Head office located in Shenzhen,
factory is in Dongguan.
TSD business scope covers TFT LCD / Capacitive touch screen / Monochrome display / HMI development,
single-chip production and sales.
|
Our Factory
◆ Operates Class 1000 & 100 cleanrooms with auto humidity control and full ESD grounding. Fully imported automation ensures high-precision, end-to-end production for consistent, reliable products. our entire workshop floor is equipped with a dedicated anti-static (ESD) grounding system to ensure product safety.
◆ Backed by advanced equipment, stringent quality control systems, and continuous technological innovation, our products are widely adopted in consumer electronics, industrial control, smart home applications, and beyond, earning extensive recognition and trust from clients worldwide.
◆ Furthermore, our seasoned R&D team stands ready to provide rapid and efficient new product development support, offering comprehensive hardware and software design solutions tailored to customer needs.
Exhibition
 |
 |
 |
|||
|
|
|
 |
 |
 |
|||
|
|
|
 |
 |
 |
|||
|
|
|
Our Certificate
The company has maintained its ISO 9001 and ISO 14001 certifications since 2017–2018, and further expanded its credentials by securing IATF 16949 and ISO 13485 between 2019 and 2020.
| Product Applications |
Applications:
Smart Wearables — smart watches, fitness bands, and health trackers
Smart Home Devices — control panels, thermostat knobs, and smart switches
Medical & Handheld Instruments — portable monitors, diagnostic tools, and handheld meters
Industrial Equipment — meters, sensors, HMI terminals, and HVAC controllers
Consumer Electronics — smart speakers, dashboards, and round-display gadgets
| Packing & Delivery |
| FAQ |
Q: How can i find the right product?
A: Please send us your requirements, we will recommend our standard products, if it’s not fit, we will do the necessary adjustment & customization.
Q: How to customize the product?
A: Customized procedures goes like this: Project scope clarification → Fill TSD Requirement Form → Engineering analysis → Cost→Evaluation → Customer confirmation → Providing drawing → Customer confirmation → Sampling → Customer approval → Mass production
Q: Do you accept sample order or small quantity order?
A: Yes, you can place sample orders for testing first, and small quantity order as pilot production (no less than MOQ)
Q: What are the payment terms?
A: We usually accept T/T, Paypal, other terms to be negotiated.
Q: What’s the lead time?
A: Usually 3~5 days for sample orders if goods are in stock, and 4~5 weeks for mass production (basing on the quantity and product)
Have any customize requirements, please feel free to contact us.
