8 inch 800*1280 vertical ips screen JD9366AB IC MIPI Interface TFT LCD Display Modules
| LCD Type | a-Si TFT,Transmissive,Normally black |
| LCD Size | 8 |
| Resolution (W x H) | 800x(RGB)x1280 |
| Outline size | 114.6(H)x 184.1(V)x2.9(T) |
| Active Area | 107.64 (H)x 172.22 V) |
| Pixel Pitch | 0.1506(H)x 0.1432(V) |
| Viewing Direction | ALL o'clock |
| Color Depth | 16.7M |
| Pixel Arrangement | RGB-stripe |
| Backlight Type | White LED*21Chip |
| Surface Luminance | 250cd/m2 |
| LCD Driver IC | JD9336AB |
| Interface Type | MIPI |
| Input Voltage | 3.3v |
Brand:
TSD
Spu:
TST080HDBJ-16
Appurtenance:
- Overview
- Related Products
8 inch 800*1280 vertical ips screen JD9366AB IC MIPI Interface TFT LCD Display Modules
TST080HDBJ-16 is a transmissive type color active matrix liquid erystal display (LCD) which uses amorphous thin film transistor (TFT) as switching devices.
This produet is composed of a TFT LCD panel, a drive IC, a FPC, and a WLED-backlight unit,The active display area is 8.0 inches diagonally measured and the native resolution is 800*RGB*1280. Features of this product are listed in the following table.
| LCD Type | a-Si TFT,Transmissive,Normally black |
| LCD Size | 8 |
| Resolution (W x H) | 800x(RGB)x1280 |
| Outline size | 114.6(H)x 184.1(V)x2.9(T) |
| Active Area | 107.64 (H)x 172.22 V) |
| Pixel Pitch | 0.1506(H)x 0.1432(V) |
| Viewing Direction | ALL o'clock |
| Color Depth | 16.7M |
| Pixel Arrangement | RGB-stripe |
| Backlight Type | White LED*21Chip |
| Surface Luminance | 250cd/m2 |
| LCD Driver IC | JD9336AB |
| Interface Type | MIPI |
| Input Voltage | 3.3v |
Have any customize requirements, please feel free to contact us.
